- Ultra Compact and Fanless Design
- Intel Apollo Lake Inside
- Support Dual 1080p Display
Low Power Consumption Cost-effective
The ultra-compact player is equipped with Apollo Lake Celeron® processors N3350/N3450 (TDP ≤6W). It's Giada's top selling model, with best price-performance ratio. It supports onboard LPDDR4 memory and eMMC5.1 storage.
Supporting Dual 1080p Display
The player adopts Intel® HD Graphics 500. It supports vivid dual 1080p video decoding. The HDMI 1.4a supports resolutions up to 4096 x 2160@24Hz, while DisplayPort 1.2 port supports 4096 x 2160@60Hz.
Fanless Design
With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device running with noise-free and dustproof. It enables this Giada® device applicable in mission critical applications.
General
- Operating System
- No OS
Processor
- CPU Model
- Intel® Celeron® N3350
- Number of cores
- 2 pcs.
Graphics
- GPU Model
- Intel® HD Graphics 500
Connections
- HDMI
- Yes x1 (Max.3840 x 2160 @30 Hz)
- DisplayPort
- Yes x1 (Max.4096 x 2304 @60 Hz)
- USB type-A
- Yes x4
Communication
- Ethernet
- Yes
Dimensions and weight
- Width
- 116.6 mm
- Depth
- 107.4 mm
- Height
- 30 mm
Packaging info
- Packaging size
- 245 x 190 x 76 mm
- Packaging weight
- 870 g
