Stand out
Inform and enthral with a Philips Q-Line Professional Ultra HD Display. This reliable solution can be up and running as quickly as you need.

Operate, monitor and maintain with CMND and Control
Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures that content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

Schedule what you want, when you want with SmartPlayer
Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

Integrated media player. Easily schedule USB content
Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback has finished.



Wireless image sharing
Nei
Haze value (%)
25
Outdoor use
Nei

Generelt

Bruksområde
Digital Signage, Møterom

Display

Operating Hours
18/7
Image diagonal
86 "
Resolution
3840x2160
Lysstyrke
400 Nits
Haze
25 %
Portrait
Ja

Functions

Protective Glass
Nei
Videoveggprosessor
Nei

Datasystem

Mediespillerplattform
No SoC (OS Free), USB mediaplayer

Lyd

Innebygd høytaler
Ja 2x10W
Utgangseffekt / kanal
10 W
Antall høyttalere
2 pcs.

Tilkoblinger

Video in
DVI-I x1
Video in
HDMI x3
Antall HDMI-innganger
2 x
Lydinnganger
3,5mm minijack x1
Lydutganger
3,5mm minijack x1

Communication

Ethernet (RJ-45)
Ja
Wi-Fi
No
Styring
Ethernet/IP (RJ-45), RS-232

TV Tuner

TV Tuner
Nei

Energy

Power Supply
AC 100-240 V; 50-60 Hz Internal Power Supply
Forbruk standby
0,5 W
Forbruk normalt
360 W
Forbruk maks
500 W
Energiklasse
G

Dimensions and weight

VESA mount interface (mm)
600x400 M8
Bredde
1 929 mm
Høyde
1 100 mm
Dypde
69,5 mm
Nettovekt
49,5 kg

Annen

Included Accessories
AC Switch Cover, IR sensor, cable (1.8 m), Philips logo, Quick start guide, Remote control and AAA batteries, RS232 daisy chain cable, USB Cover and screw, Wire Clamper (x 3), AC power cord
Warranty
3 år

Pakkeinformasjon

Pakkestørrelse
2 125 x 245 x 1 190 mm
Pakkevekt
65,30 kg
