The POE90U1BT Single Port PoE Injector from Pelco is designed to meet the data rate and power requirements of IP cameras with high-quality streaming video capabilities. It provides total power output of 90W, which meets the IEEE 802.3bt standard for detection, connection, disconnection, and fault protection. It is compatible with 10/100/1000Base-T systems. This injector supports AC input voltage of 100 to 240 VAC ± 10% and an input frequency of 47 to 63 Hz. The maximum output load current is 1.6A at 56 VDC.
Features:
- Diagnostic LEDs
- Broken wire detection
- Overcurrent and overvoltage protection
- The output can be shorted permanently without damage
- Power cord required for operation (available separately)
- Ethernet (RJ-45)
- Ja
Nätverk
- Data överföringshastighet
- 1 Gbit/s
- Antal LAN (RJ-45) anslutningar
- 2 st.
- Antal LAN (RJ-45) In
- 1 st.
- Antal LAN (RJ-45) Ut
- 1 st.
Electrical specifications
- Effekt
- 90 W
- PoE Standard
- IEEE 802.3bt Type 4 (PoE++)
Mått och vikt
- Bredd
- 80 mm
- Djup
- 166 mm
- Höjd
- 44 mm
- Nettovikt
- 0,5 kg
Förpackningsinfo
- Förpackningsstorlek
- 219 x 152 x 65 mm
- Förpackningsvikt
- 757 g
- Streckkod
- 700880440346
