High Impact. Streamlined Value
Bring the brilliance of fine-pitch LED to value-driven environments, without compromising on performance. Purpose-built for corporate meeting rooms and digital signage, the Sharp E Series delivers vivid content clarity and brightness for excellent visibility.
Available in standard-size bundles, it includes all the components needed for seamless integration of large format displays, free from distracting bezels. The slim, lightweight design supports easy installation, either wall-mounted or free-standing, while front access to all components simplifies maintenance. A durable metal chassis ensures long-term reliability, in line with Sharp’s reputation for engineering quality.
An SoC-based controller enables wireless content sharing and seamless connectivity with external devices. Whether presenting or collaborating, the E Series supports intuitive operation and minimal setup.
Designed to meet the demands of modern visual communication, the E Series combines professional-grade performance with streamlined deployment, bringing high-impact LED to a broader range of applications.
Benefits
- Low-profile integration – the super slim and light weight modules align with perfection to create a large digital canvas which integrates unobtrusively into any environment.
- Front serviceable modules – with front access to the LED modules, maintenance is easy.
- Slim design – with a flush rear profile, LED modules can be integrated very close to the wall with minimal gap necessary due to very low heat emission.
- Care-free installation – with bundled solutions that deliver all you need to get your LED video wall up and running.
Display
- Bilddiagonal
- 217 "
- Upplösning Display
- 3840x2160
- Pixel pitch
- 1,2 mm
- Diodtyp
- 3-in-1 SMD (Black), SMD 1010
- Uppdateringsfrekvens
- 3 840 Hz
- Ljusstyrka (Max)
- 600 Nits
- Betraktningsvinkel
- 170 ° horizontal / 160 vertical
LED Modul/Kabinett
- Antal kabinett/display (BxH)
- 8x8
- Antal moduler/kabinett (BxH)
- 4x1
- Upplösning Kabinett
- 480x270
- Upplösning Modul
- 120x270
Anslutningar
- Bildanslutning in
- 3G-SDI, DVI-D, HDMI
- Ethernet
- Ja
Energi
- Förbrukning Max/m2
- 617 W
- Förbrukning Max tot.
- 8 000 W
Mått och vikt
- Bredd
- 4 812 mm incl. powerbar
- Höjd
- 2 756 mm incl. powerbar
- Djup
- 50 mm incl. powerbar
- Nettovikt
- 376 kg incl. powerbar
Övrigt
- Service access
- Front Service
- IP Klassning
- IP20
- Min temp vid drift
- −20 Celsius
- Max temp vid drift
- 40 Celsius
- Medföljande Tillbehör
- 1x LED Controller; LED Modules (16 Cabinets, 64 Pixel Cards); Overframe Kit (4x4); Pixel Card Removal Tool; Powerbar (depending on version); Spare Parts Kit; Wall mount (4x4)
- Garanti
- 2 år
Förpackningsinfo
- Förpackningsstorlek
- 1 200 x 800 x 800 mm
- Förpackningsvikt
- 100,00 kg
