The BSS OMNI-VD-330 is an AV-over-IP decoder for streaming 4K60 4:4:4 video with H.264 or H.265 compression, along with audio and control. Optimized for bandwidth-efficient AV distribution over WANs (wide-area networks) or shared networks, the OMNI-VD-330 is ideal for applications such as live presentations, digital signage, media playback, camera feeds, and content distribution in classrooms, meeting spaces, convention centers, retail environments, and hospitality venues.
The OMNI-VD-330 also features powerful USB video and audio integration over USB-C. AV streams can be recorded directly to external USB storage up to 2 TB, with the option to schedule transfer of recordings to a network storage location. Additionally, Dante audio and H.26x streams can be converted into USB audio (UAC) and USB video (UVC), enabling a host PC to access network AV streams directly for recording, conferencing, or livestreaming applications.
Along with high-performance networked AV streaming, the OMNI-VD-330 is Dante AV-H enabled for interoperability with third-party Dante AV-H encoders for video streaming up to 4K60 4:2:0. Integrators can configure and manage OMNI 300 systems using Dante Controller, Dante Domain Manager, and Dante Director, while Dante Studio allows video streams to be monitored or brought directly into conferencing, production, recording, or livestreaming workflows.
The OMNI-VD-330 is designed for modern professional AV installations, with essential integration features including PoE+ remote powering, a low-power standby mode, video source preview, custom image and slideshow presentations, open APIs for third-party control, and 4K video scaling.
Features
- High-performance 4K60 4:4:4 H.264 or H.265 decoding, plus audio and control
- USB video and audio over USB-C for recording streams or interfacing with a host PC
- Independent H.26x stream decoding and conversion to USB video (UVC)
- Two-channel Dante audio input and output (2x2) with conversion to USB audio (UAC)
- Dante AV-H enables third-party networked AV interoperability, plus system management from Dante Controller, Dante Domain Manager, and Dante Director
- Video preview from the built-in web interface or a touch panel
- Supports custom image and slideshow presentations
- Enhance video presentations with 4K video scaling and seamless switching
- PoE+ powered with low-power (standby) mode to conserve energy
- Enterprise-grade network security and standards including IEEE 802.1x, HTTPS, TLS, AES-256 encryption, LDAP, VLAN tagging, and QoS
- AVX Suite for OMNI 300 system configuration and management
- HARMAN HControl and BSS Direct Control provide open APIs for third-party control integration
Allmänt
- Produktserie
- OMNI 300
- Extender typ
- Mottagare (Rx)
- Teknologi
- Dante AV-H, H.264, H.265
Bildspecifikation
- Max stödd upplösning
- 4096x2160
- Uppdateringsfrekvens
- 60 Hz
- Chroma subsampling (4K)
- 4:4:4
Anslutningar
- Bildanslutning in
- IP stream (RJ-45)
- Bildanslutning ut
- HDMI
- Ljudanslutning in
- USB-C 2x2 ch of Dante
- Ljudanslutning ut
- Euroblock lågnivå
- Ljudanslutning ut
- USB-C 2x2 ch of Dante
- Styrning
- Ethernet/IP (RJ-45)
- Styrning
- IR kabelanslutning IR Out
- Styrning
- RS-232
Kommunikation
- Switch Data Rate
- 1GbE
Energi
- Strömförsörjning
- PoE+, conforms to IEEE 802.3at. Option AC power supply 2.0 Amp @ 12 Volts DC; 100-240 Volts
Mått och vikt
- Bredd
- 200 mm
- Djup
- 127 mm
- Höjd
- 26,6 mm
- Nettovikt
- 0,45 kg
Övrigt
- Medföljande Tillbehör
- 2x Painted L-Brackets
