  • The cabinet features a highly integrated, lightweight, and streamlined design with a magnetic butterfly-frame, enabling fast horizontal splicing and flexible combinations.
  • Incorporates proprietary lossless image processing and ultra-low grayscale control technologies, delivering delicate, smooth visuals and outstanding dynamic color performance.
  • Supports multiple remote content management methods, including local control, USB drive input, and PC-based operation.
  • Fully self-developed display control system ensures end-to-end stability, security, and controllability. System modules can be easily maintained or replaced, with front-access LED modules supporting single-pixel repairs.
  • Allows for multi-unit cascading display with a built-in sending card, eliminating the need for external control devices.
  • Multiple installation options available: mobile stand, wall mount
  • Optimized for close-range viewing scenarios with HOB LED panel protection, offering enhanced resistance to moisture, impact, and environmental stress.
  • Supports multiple configuration methods including local remote control, software, and web interface, offering more convenient operation.

Accessory
50 LED lamp beads, 10 IC chips, 1 network cable, 1 power cable, 1 HDMI cable, 1 multilingual user manual, 1 remote control, 1 magnetic adjustment rod, 1 cable clip, 1 Phillips screwdriver, 1 hex key wrench, 1 power cable, 2 spare LED modules, 1 spare HUB Board



Display

Upplösning Display
480x1350
Pixel pitch
1,25 mm
Diodtyp
SMD Triad LED (with glue)
Uppdateringsfrekvens
3 840 Hz
Ljusstyrka (Max)
600 Nits
Betraktningsvinkel
160 °

LED Modul/Kabinett

Antal kabinett/display (BxH)
5
Antal moduler/kabinett (BxH)
2x2

Mått och vikt

Nettovikt
33,4 kg

Övrigt

Service access
Front service
