The trend of moving matrix switching into the Ethernet network is inevitable and SDVoE already delivers capabilities far beyond that of a traditional matrix switch. Historically it has been simple to design AV over IP systems of up to 96 I/Os using a single switch using Layer-2 Multicast IGMP. However, larger installations required data center-class 100G Ethernet switches with more complex Layer-3 Multicast Routing techniques, adding complexity and cost to the Ethernet infrastructure. As SDVoE systems become ever larger, a new class of switches has come to market. The M4500 switches combine the configurability of a matrix switch with the power and scalability of Ethernet to support hundreds of AV over IP endpoints, at a price point dramatically cheaper than comparable matrix switches. Removing the need for Layer-3 PIM routing, these new switches offer IGMP Plus and greatly simplify system architectures with the same well-known IGMP techniques across the entire AV over IP network.
- Managerbar
- Ja
Allmänt
- Formfaktor
- 19" Rack, 1U
Hantering / Administration
- Managerbar
- Hybrid managed
Anslutningar
- Primära portar
- 48 x
- SFP Portar
- 48 x
Nätverk
- Primär Porthastighet
- 100 Gbit/s
- IGMP Support
- Ja
Dataöverföring
- Switch kapacitet
- 4 000 Gbit/s
PoE
- PoE
- Nej
Energi
- Förbrukning max
- 426 W Max
Mått och vikt
- Bredd
- 440 mm
- Djup
- 508 mm
- Höjd
- 43,2 mm
- Vikt
- 9,78 kg
Förpackningsinfo
- Förpackningsstorlek
- 890 x 600 x 190 mm
- Förpackningsvikt
- 16,77 kg
